All-steel overhead platform

★ Sky platform is specially designed for experiments with high precision requirements and anti-interference, and is a basic supporting experimental equipment with strong damping effect;
★ Can control the use of various equipment vibration interference, resistance to highway vehicles and ground friction vibration on the use of interference, resistance to the natural movement of the earth on the use of interference, resistance to natural changes in the weather on the use of interference;
★ Ensure the accuracy in the experimental process.
★ Common size: 900mm*600mm*800mm

Product Details

Technical parameters

 The platform is designed for three-stage shock absorption, namely: table body, table top, table top and instrument; three-stage anti-vibration design, can effectively ensure the weighing accuracy of the instrument;

1, the main support frame

 1.1, the use of 2.0mm thick galvanized steel and 60x40mm steel pipe welded into the type of processing and production, the surface epoxy resin powder coating;

 1.2 The connecting parts are made of 1.0mm thick cold rolled steel plate, with epoxy resin powder coating on the surface;

 1.3 Adopting the whole standard combination structure;

 1.4 Adjustable combination of feet: anti-slip, shock absorption, acid and alkali corrosion resistance, strong load-bearing capacity and other features and functions;

2、Countertop

Countertop Description: Adopt high leveling marble using natural high-quality marble plate, 30mm thick (10,000 points) and 60mm (100,000 points), the work surface is finely polished, and there are anti-vibration shims inside. Wear-resistant, impact-resistant, inertia power, anti-vibration performance is good;

Description of anti-vibration gasket: It can prevent violent vibration and noise transmission, and prevent low-frequency anti-vibration;

Description of aniseed weight capacity: 1~5 Description of thickness: 13 Description of friction coefficient: 0.71.



Product Characteristics

All-steel overhead platform
